Setting items	Detailed items	Description	Page
Audio	Subwoofer Level Adjust	Adjusts the subwoofer channel volume for all input sources.	link
	Bass Sync	Synchronizes the timing of the low frequency sound.	link
	Surround Parameter	Adjusts surround sound parameters.	link
	M-DAX	Expands the low and high frequency components of compressed audio content such as MP3 files to enable richer audio playback.	link
	Volume	Sets the MAIN ZONE (room where the unit is located) volume setting.	link
	Audyssey	Makes Audyssey MultEQ_® XT32, Audyssey Dynamic EQ_®, Audyssey Dynamic Volume_® and Audyssey LFC_TM settings.	link
	Dirac Live	Select a Dirac Live filter.	link
	Graphic EQ	Adjusts the tonal quality for each speaker using a graphic equalizer.	link
Video	HDMI Setup	Makes settings for HDMI Audio Out, HDMI Pass Through and HDMI Control settings.	link
	Output Settings	Makes settings for video output.	link
	On-Screen Display	Selects the on-screen display user interface preferences.	link
	Screensaver	Sets the screen saver setting.	link
	4K/8K Signal Format	Sets signal format options for your 4K or 8K video equipment.	link
	HDCP Setup	Sets the HDCP version for each HDMI input source.	link
	TV Format	Selects the format used to send video to the TV.	link

Setting items	Detailed items	Description	Page
Inputs	Input Assign	Changes input connector assignment and the audio input mode.	link
	Source Rename	Changes the display name for input source.	link
	Hide Sources	Selects source inputs to hide on the user interface and front panel displays.	link
	Source Level	Adjusts the input level for the current source.	link
Speakers	Audyssey_® Setup	The acoustic characteristics of the connected speakers and listening room are measured and the optimum settings are made automatically.	link
	Manual Setup	Sets up the speakers manually or changes Audyssey_® Setup, Dirac Live_® Room Correction settings.	link
	Dirac Live Setup	Displays information about using Dirac Live Room Calibration.	link
Network	Information	Displays network information.	link
	Connection	Configures the network connection.	link
	Settings	Configures the network settings (DHCP and IP address).	link
	Network Control	Enables network communication in standby power mode.	link
	Friendly Name	Edits the name of this unit that is displayed on the network.	link
	Diagnostics	Tests the network connection.	link
	AirPlay	Settings for Apple AirPlay.	link
	Spotify Connect	Toggles access to Spotify Connect.	link
	TIDAL Connect	Toggles access to TIDAL Connect.	link
	Wi-Fi and Bluetooth	Toggles power to the Wi-Fi and Bluetooth radios.	link

Setting items	Detailed items	Description	Page
HEOS Account	[When the user is signed out of the HEOS account]
	I have a HEOS Account	Select to sign in.	link
	Create Account	Creates new HEOS account.	link
	Forgot Password	If you forgot your password, we'll send you an email with instructions to reset it.	link
	[When the user is signed in to the HEOS account]
	Signed in as	Displays your HEOS account.	link
	Change Location	Selects your location.	link
	Change Password	Changes your HEOS account password.	link
	Delete Account	Deletes your HEOS account.	link
	Sign Out	Signs out of your HEOS account.	link

Setting items	Detailed items	Description	Page
General	Language	Selects the language for the on-screen user interface.	link
	Owner's Manual	Access the online Owner's Manual from your mobile device.	link
	ECO	Configures the ECO Mode and Auto Standby energy-saving functions.	link
	Bluetooth Transmitter	Sets Bluetooth transmitter settings.	link
	ZONE2 Setup	Makes settings for audio playback with ZONE2.	link
	Zone Rename	Changes the display title of each zone to one you prefer.	link
	Smart Select	Sets the “Smart Select” parameters and display name.	link
	Trigger Out	Select the conditions for activating trigger out function.	link
	Front Display	Makes settings related to the display on this unit.	link
	Firmware	Checks for the latest firmware information about updates and updates the firmware, and sets up the notification message display.	link
	Information	Shows information about this unit settings, input signals, etc.	link
	Usage Data	Selects whether or not to send anonymous usage data to Marantz.	link
	Save & Load	Save and restore device settings by using a USB memory device.	link
	Setup Lock	Protects settings from inadvertent changes.	link
	Reset	Various settings are reset to the factory default values.	link

Setting items	Detailed items	Description	Page
Setup Assistant	Begin Setup...	Performs basic installation/connections/settings from the beginning according to the guidance indicated on the TV screen.	Page 9 of the separate manual “Quick Start Guide”
	Language Select	Sets individual setting items according to the guidance displayed on the TV screen.
	Speaker Setup
	Speaker Calibration
	Network Setup
	TV Audio Setup
	Input Setup
	Mobile Apps
