Specifications

Rated output:

(Normal operation)
8-channel driving
100 W + 100 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.05 % T.H.D. LPF 20 kHz)
125 W + 125 W (4 Ω/ohms, 1 kHz with 0.05 % T.H.D.)

(Bridge operation)
4-channel driving
200 W + 200 W (4 Ω/ohms, 1 kHz with 0.05 % T.H.D.)

Output connectors:

(Normal operation)
4 – 16 Ω/ohms

(Bridge operation)
4 – 16 Ω/ohms

S/N (IHF-A):

OPTICAL IN: 103 dB
LINE IN: 100 dB

Frequency response:

20 Hz - 40 kHz ±3 dB

Input sensitivity/impedance:

200 mV/20 kΩ/kohms

Maximum allowable input level:

2.5 V

Operating temperature:

41 °F - 95 °F (5 °C - 35 °C)

Power supply:

AC 100 - 240 V, 50/60 Hz

Power consumption:

265 W

Power consumption in Deep Standby Mode:

0.5 W

Power consumption in Quick Start Mode:

20 W (User selectable)
